Fan:
- Enclosure made of galvanized steel sheet.
- Impeller with forward-curved blades, made of galvanized steel sheet.
Motor:
- High efficiency (HE) motors to comply with ErP 2015.
- Closed motors with built-in thermal protection, class F, with ball bearings, IP54 protection.
- Single-phase 220-240V AC-50Hz
- Maximum air temperature to be transported: -20ºC to +60ºC.
- Speed 1250 rpm 1 speed
- Decibels 70
- Capacitor 20 μF
- Power 550W
- Airflow 3000 m³ - hour
- Connection via plug connector
- Net weight 15.50 kg
- Gross weight 14.90 kg
- Packaging dimensions 420x395x400mm
Finish:
- Corrosion-resistant galvanized steel sheet
- Sealed ABS box for capacitor and connections.
- With 4 silent-blocks
